PECMD commands in WinPE

Most Chinese WinPE builds rest on one core binary: PECMD.EXE, a small command interpreter with 70+ commands. It is not cmd.exe. It boots the PE, draws login UIs, loads a shell, mounts drivers, and runs a config file as a script.

Originally compiled from twblogs.net. This English edition is a usable reference: full coverage of what PECMD is and the commands that matter, with the exhaustive per-command tables summarized.

A WinPE boot environment on a repair bench

What PECMD is

PECMD is both:

A script host — a .txt / config file of PECMD commands that runs at boot (LOAD)
A command-line tool — PECMD.EXE <COMMAND> ... from a running PE (not every command works on the CLI)

A typical boot path looks like:

INIT CIK
LOGO
TEXT Registering components...
DEVI %SystemRoot%\DRV.CAB
SHEL %SystemRoot%\EXPLORER.EXE

INIT registers a shell environment and user folders. SHEL locks Explorer (or another shell) and hooks shutdown so Start → Shut down runs PECMD SHUT. Everything between is PECMD script.

Commands live in four families. Window-control commands only work between _SUB and _END. Subroutine commands (_SUB / _END / CALL of a proc) only work inside a config file, not on the CLI.

System variables

PECMD exposes Windows special folders as variables you can expand with %Name%:

Variable	Meaning
`CurDir`	current directory
`Desktop`	desktop
`Favorites`	favorites
`Personal`	My Documents
`Programs`	Programs menu
`SendTo`	Send To
`Start`	Start menu
`Startup`	Startup folder
`QuickLaunch`	Quick Launch
`SystemDriver`	system volume (legacy name in PECMD)
`SystemRoot`	Windows folder

INIT also creates those folders under %USERPROFILE%. The profile volume must be writable or INIT fails.

After INIT C, optical-drive letters appear as CDROM, CDROM0, CDROM1, … Refresh them with a bare ENVI at a prompt.

Command families

1. Window controls and subroutines CHEK MENU LABE EDIT GROU IMAG ITEM MEMO PBAR TIME RADI

These only exist inside a _SUB … _END window. Geometry is always L<left>T<top>W<width>H<height>. Names must be unique and must not collide with environment variables. The first character of a name cannot be $.

2. String processing LPOS LSTR MSTR RPOS RSTR STRL

Unicode-aware. Used to slice %CurDate%, paths, and user input.

3. Subroutine markers _SUB _END

Must pair. Cannot nest. Cannot appear on the CLI. Must sit on their own lines — not inside FIND / IFEX / TEAM.

4. Everyday commands BROW CALC CALL DATE DEVI DISP EJEC ENVI EXEC EXIT FBWF FDIR FDRV FEXT FILE FIND FORX HELP HKEY HOTK IFEX INIT KILL LINK LIST LOAD LOGO LOGS MAIN MD5C MESS MOUN NAME NUMK PAGE PATH RAMD REGI RUNS SEND SERV SHEL SHOW SHUT SITE SUBJ TEAM TEMP TEXT TIPS UPNP USER WAIT WALL

The commands you actually write

`_SUB` / `_END` — define a procedure or a window

_SUB <procName>
...
_END

_SUB <winName>,<shape>,[title],[onClose],[icon],[type]
...
_END

Procedure: _SUB DoLoop … _END. Only a matching CALL DoLoop runs the body; the main script skips it. Put procedures at the top of the file.
Window: shape is W360H440 (centered) or L10T10W360H440. onClose must be a PECMD command. Icon is file#id. Type: - no caption, # no border, a number is opacity; >99 hides the window.
Title after create: ENVI @Windows1=New title.
CALL @Windows1 opens the window and blocks until it closes. Do not CALL @ another window from inside a window.

`CALL` — DLL, procedure, or window

CALL $SHELL32.DLL,DllInstall,#1,U
CALL DoLoop
CALL @Window1

$dll,fn,[#]arg… — stdcall export, up to four args. # means integer; otherwise Unicode string. Omit fn and it calls DllRegisterServer.
No prefix — call a _SUB procedure in this config file (not on the CLI).
@name — show that window and wait.

`EXEC` — run a program

EXEC [=][!][@][$][&]<path> [args]

Prefixes stack:

Prefix	Meaning
`=`	wait for exit
`!`	hidden
`@`	run on the Winlogon desktop (no UI; good for registration)
`$`	`ShellExecute` — open a non-exe (`.txt`, `.bmp`)
`&`	hook `ExitWindowsEx` so Start → Shut down runs `PECMD SHUT`

EXEC =!CMD.EXE /C "DEL /Q /F %TEMP%"
EXEC &EXPLORER.EXE

The PE shell itself is loaded this way.

`SHEL` — load and lock the shell

SHEL <exe>,[md5-of-password],[retries]

Like EXEC $ plus: hook shutdown, and relaunch the shell if it is killed. Optional login password (max 12 chars, stored as MD5). Default retries: 3. Must come after HOTK. Config-file only.

SHEL %SystemRoot%\EXPLORER.EXE,e10adc3949ba59abbe56e057f20f883e,5

Put LOGO before a passworded SHEL. WALL must also come before SHEL.

`INIT` — minimum PE bring-up

INIT [C][I][K][U]

Registers a Windows shell, creates user folders, installs a keyboard hook.

Flag	Meaning
`C`	write optical letters into `CDROM*` env vars
`I`	install some PECMD actions on the tray menu
`K`	install the low-level keyboard hook now (Ctrl+Alt+Del → Task Manager). Public PE builds should usually omit `K`
`U`	write USB letters into `USB*` vars (unfinished)

Config-file only. After INIT, SHEL is enough for a minimal PE.

`ENVI` — environment and control text

ENVI [$|@|*][name][[=]value]

no prefix — process env. Omit =value to delete.
$ — system env (inherited by later EXEC)
@ — set a window / control title or property (ENVI @Edit1=%Edit1%, ENVI @Check1.Check=1, ENVI @Btn.Enable=0)
* alone — write CDROM* letters
$ alone — re-init user folders
no args at a prompt — refresh env

ENVI TEMP=%SystemDrive%\TEMP

`IFEX` and `FIND` — branch

IFEX <cond>,[cmdIfTrue][!cmdIfFalse]

Conditions:

memory: MEM>127 (MB)
free disk: C:>500
key: KEY=17
path (wildcards ok): C:\Windows
numeric var: $%Val%=10

Comparators: < > =. , after the condition can be *. Nesting is allowed; a nested IFEX/FIND cannot use !.

IFEX C:\Windows,!MESS Directory C:\Windows is missing.@Check#OK
FIND MEM>127,CALL EXPLORER_SHELL!CALL CMD_SHELL

FIND is the sibling — same idea, often used as FIND $%CancelIt%=YES,EXIT.

`CALC` — arithmetic

CALC [#]<dest> = <a> <op> <b>

# = int; omit = double (4 decimal places). Ops: + - * /. Unset vars count as 0. Chain several CALCs for a longer expression. Compare with IFEX.

CALC #Sum = 128 + 32
CALC Result = %Datum1% * %Datum2%

`TEAM` — run a sequence

TEAM TEXT Loading desktop|LOGO|SHEL %SystemRoot%\EXPLORER.EXE|WAIT 3000

| separates PECMD commands. Do not nest IFEX/FIND inside TEAM.

`LOAD` / `EXIT`

LOAD runs another config file as a procedure. EXIT leaves the current CALL or LOAD — not the whole PECMD process.

IFEX $%Val%=10,EXIT!ENVI Val=

`DEVI` — drivers from a CAB

DEVI [$]<cab-or-folder>

$ = extract and install; omit = extract only. Uses PECMD’s own search (not SetupAPI), so one device may match several INFs. Layout: one driver per folder, INF first in that folder, INFs pre-processed. Companion tool: XCAB.

Unpack targets:

INF → %SystemRoot%\INF
SYS → %SystemRoot%\SYSTEM32\DRIVERS
other → %SystemRoot%\SYSTEM32
# in a CAB name is a path separator: SYSTEM32#WBEM#MOF#X.MOF

`SHUT` — power

SHUT [H|E|R|S]

Arg	Action
(none)	power off (fast; may not flush everything)
`R`	reboot
`E`	eject optical, wait 10s, power off
`H`	hibernate (full Windows, hibernate enabled)
`S`	suspend (full Windows)

Works on the CLI. Pair with EXEC &EXPLORER.EXE so the Start menu calls this.

`WAIT`

WAIT [-][ms],[var]

- = any key cancels the wait
0 = pause until a key (A–Z, 0–9); result in var or %PressKey%
do not spam WAIT 0

WAIT 2000
WAIT 0,PKey

`FILE` / `PATH` / `FDIR` / `FDRV` / `FEXT` / `NAME`

Path plumbing you will use constantly:

Command	Job
`FILE`	file ops (copy / delete / exist — see help in-PE)
`PATH`	search or set PATH
`FDIR dest=C:\Windows\System32\calc.exe`	directory of a file (no trailing `\`)
`FDRV`	drive letter of a path
`FEXT`	extension
`NAME`	file name without path

String commands

All Unicode. Length limit on STRL source is 2K.

Command	Job	Note
`STRL len=一二三四五`	length	example → `5`
`LSTR dest=1234567890,2`	left n chars
`RSTR dest=1234567890,2`	right n chars	→ `90`
`MSTR dest=src,start,count`	mid
`LPOS` / `RPOS`	left / right index of a substring	feed `DATE` output (`yyyy-m-d\|dow\|h:m:s`)

If n < 1 or past the end, LSTR/RSTR return the whole string.

`REGI` / `HKEY` (registry) / `RUNS`

REGI is the general registry command (add / delete / query — run HELP in-PE for the full flag list). RUNS exe,display-name is a shorter way to write a Run key; separator is the rightmost * or leftmost ,. Config-file only.

`MOUN` / `FBWF` / `RAMD` / `SERV`

MOUN — mount a volume or enable the writable overlay (must precede FBWF)
FBWF P20 L32 H64 — File-Based Write Filter cache: percent of RAM, min MB, max MB. Flags may be used alone (FBWF L64)
RAMD — ramdisk
SERV [!]name — start a service/driver; ! stops. SERV FBWF is the usual way to make a CD-based PE writable

`SHOW` / `SUBJ` / `SITE`

SHOW [disk|F|R][:part],[letter] — assign letters to hidden / removable partitions. 0:1,H = hd0 partition 1 → H:. R:1,U = first removable partition → U:. F:0 = all hidden fixed partitions, auto letter
SUBJ B:,X:\PE_Tools — SUBST-like virtual drive. Omit the path to delete. The letter must be exact or you can delete a real volume
SITE path,+H +R — attributes A H R S with + / -

`LINK` — shortcut

LINK [!]shortcut,target,[args],[icon#index],[comment],[cwd]

No .lnk on the shortcut path. ! = start minimized. Target must exist.

LINK !%Desktop%\PPPoE,RASPPPOE.CMD,,RASDIAL.DLL#19

`KILL`

KILL [\<windowTitle>|process.exe]

\ = close a window (omit title = close the current _SUB window). No \ = kill by image name (all matches). Omit both = kill PECMD’s parent.

`HOTK` / `HKEY` / `SEND`

HOTK — up to 8 system hotkeys that launch an .exe/.cmd/.bat. Config-file only. Must run before SHEL. Result stored under HKLM\SOFTWARE\PELOGON
HKEY — hotkey that runs a PECMD command; only valid inside _SUB…_END
SEND 0x12_,0x09_,0x09^,0x12^ — synthesize keys (_ down, ^ up). Example is Alt+Tab

HOTK #255,PECMD.EXE SHUT E
HKEY Ctrl+Alt+#0x41,DISP W800H600B16F75

#255 is the power key on many boxes.

`DISP` / `LOGO` / `WALL` / `TEXT` / `TIPS` / `MESS`

Command	Job
`DISP W1024 H768 B32 F70 T5000`	resolution / depth / refresh / wait ms. Any group can stand alone (`DISP F75`)
`LOGO`	splash / login bitmap
`WALL file`	wallpaper; before `SHEL`; config-file only
`TEXT line\nline#0xFFDDDD L4 T720 R300 B768 $20`	text on the logon bitmap or desktop. Empty text clears the last rect. `*` keeps previous text
`TIPS title,body\nline,5000,1,#1`	balloon. Icon 0–3 = none/info/warn/error; `@aL600T400` = on-screen arrow tip. Pair with `WAIT` so PECMD outlives the tip
`MESS`	message box

`BROW` — file / folder dialog

BROW Boot_Ini,C:\Windows\BOOT.INI,Pick a file,INI
BROW Tag,*C:\Windows,Pick a folder

Prefix on the path: none = open file, * = folder, & = save file. Result in %Var%. Must run after INIT or from the desktop.

`DATE`

DATE SysDate

Stores yyyy-m-d|dow|h:m:s in the var, or %CurDate% if omitted. Slice with LPOS / LSTR / RSTR.

`HELP`

No args — print the in-PE help. Running PECMD.EXE with no command does the same.

Interpreting PECMD at a command line

Window controls (inside `_SUB` … `_END` only)

Geometry is always L T W H. After create, talk to the control through ENVI @Name=… and %Name%.

Command	Control	Notes
`ITEM`	button	event = PECMD command; icon `file#id`; state ≠0 = disabled
`CHEK`	checkbox	state `1`/`-1` checked; `0`/`2`/`-2` unchecked; negative = grayed. `ENVI @Name.Check=` / `.Enable=`
`EDIT`	single-line edit	type `>0` password, `<0` disabled. Enter fires the event. `.ReadOnly=`
`LABE`	static label	`\n` for lines
`LIST`	combo	items `A\|B\|C`; `%Name%` is the selected string
`MEMO`	multiline memo
`MENU`	menu
`IMAG`	picture	any Windows image; keep it small
`PBAR`	progress bar
`RADI`	radio	group with `GROU`
`GROU`	group box
`TIME`	timer	period in ms; `0` = paused. `ENVI @T=0` pauses; `ENVI @T=10000` restarts
`PAGE`	tab / page

Example button:

ITEM Button3,L32T108W300H54,Explorer,EXEC explorer.exe,%SystemRoot%\explorer.exe

Compact catalog of the rest

These appear in Chinese PE scripts; HELP in a live PE is the authoritative flag list.

Command	One-line job
`EJEC [C-\|U-\|R:]`	eject optical / remove USB (unfinished; prefer the tray if the PE has it). Do not put in a config; `INIT I` adds it to the tray
`LOGS`	write / rotate a log
`MAIN`	main-window / instance helpers
`MD5C`	MD5 a file (pair with `SHEL` passwords)
`MOUN`	mount / overlay
`NUMK`	num-lock state
`PAGE`	paging UI
`RAMD`	ramdisk
`REGI`	registry
`UPNP [-pnp]`	BartPE Plug-and-Play payload baked into PECMD (`$` shows UI). Blocking
`USER name*company`	”Registered to” on My Computer. Config-file only
`TEMP Delete` / `TEMP Setting`	wipe or relocate `%TEMP%`. Desktop only, not in the boot script. `@Delete` skips the confirm
`FONT`	install / search fonts (often paired with `IFEX KEY=`)

A minimal PECMD boot script

INIT CI
LOGO
TEXT Starting WinPE#0xFFFFFF L20 T700 R400 B760 $18
DEVI %SystemRoot%\DRV.CAB
ENVI TEMP=%SystemDrive%\TEMP
LINK %Desktop%\Cmd,CMD.EXE
WALL %CurDir%\wall.jpg
HOTK #255,PECMD.EXE SHUT E
SHEL %SystemRoot%\EXPLORER.EXE
WAIT 1000
TIPS PE,Desktop is up,4000,1

Add a window procedure at the top if you need a first-run chooser (CALL @Setup after INIT). Keep _SUB / _END out of TEAM / IFEX / FIND.

Rules that save hours

Config vs CLI. _SUB, _END, CALL proc, INIT, SHEL, HOTK, WALL, RUNS, USER are config-only.
Order. HOTK before SHEL. WALL before SHEL. MOUN before FBWF. BROW after INIT.
Names. Unique, no $ prefix, no collision with env vars. _SUB names across one file must not be similar.
Windows. Controls only between _SUB and _END. CALL @win blocks. Do not nest window CALLs.
Shutdown. EXEC &EXPLORER.EXE (or SHEL) so the Start menu hits PECMD SHUT.
Writable space. INIT needs a writable %USERPROFILE%. CD PE: SERV FBWF after a proper MOUN / FBWF.
Help. PECMD.EXE with no args, or HELP, dumps the build you actually have — forks diverge.

What PECMD is

System variables

Command families

The commands you actually write

_SUB / _END — define a procedure or a window

CALL — DLL, procedure, or window

EXEC — run a program

SHEL — load and lock the shell

INIT — minimum PE bring-up

ENVI — environment and control text

IFEX and FIND — branch

CALC — arithmetic

TEAM — run a sequence

LOAD / EXIT

DEVI — drivers from a CAB

SHUT — power

WAIT

FILE / PATH / FDIR / FDRV / FEXT / NAME

String commands

REGI / HKEY (registry) / RUNS

MOUN / FBWF / RAMD / SERV

SHOW / SUBJ / SITE

LINK — shortcut

KILL

HOTK / HKEY / SEND

DISP / LOGO / WALL / TEXT / TIPS / MESS

BROW — file / folder dialog

DATE

HELP

Window controls (inside _SUB … _END only)
